4040 RO Membrane | 4”×40” Reverse Osmosis Element (TFC) | STARK

4040 Reverse Osmosis (RO) Membrane Element — thin-film composite (TFC) polyamide, 4” × 40” size, compatible with standard 4040 pressure vessels. Designed for brackish water, low-energy and fouling-resistant duties in commercial and light-industrial RO systems. Typical nominal salt rejection ≥ 99% with permeate flows in the 2,000–2,800 GPD range under standard test conditions.

Note: Final performance depends on feed quality, temperature and operating pressure. We engineer the element selection to your water analysis and pretreatment.

빠른 견적 받기

제품 설명

The STARK 4040 RO membrane uses a high-selectivity TFC polyamide layer to reject dissolved salts, silica and organics. It fits any standard 4040 housing, making it an easy retrofit for most commercial RO skids. Options include brackish-water high rejection, low-energy (LE) for reduced operating pressure, and fouling-resistant (FR) designs for challenging feeds.

  • Stable permeate quality: nominal rejection ≥ 99% on NaCl at 25 °C; smooth surface polyamide for consistent performance.
  • Energy flexibility: standard BW elements run ~150–225 psi; LE options target lower pressure at similar flux.
  • Serviceability: fits common 4040 vessels; EPDM brine seal; standard 3/4” interconnector ID.
  • Designed for pretreatment trains: pair with 20 µm → 5 µm cartridges, carbon/anti-scalant, and UF/clarification as needed to control SDI and biofouling.

Engineering transparency: All ratings are typical and configurable. Guarantees are confirmed against your feed analysis (TDS/SDI, temperature, chlorine, scaling indices) and the selected operating window.

제품 매개변수

Technical Parameters (typical values; model-dependent)

Membrane Type Thin-Film Composite (TFC) Polyamide
Element Size 4.0″ × 40″ (4040), OD ~3.9″, ID 0.75″
Active Area ~7.5–8.5 m² (80–90 ft²), depending on model
Nominal Salt Rejection ≥ 99.0% (BW); ≥ 99.2–99.5% for high-rejection variants
Typical Permeate Flow ~2,000–2,800 GPD (7.6–10.6 m³/d) at 25 °C, 2,000 ppm NaCl, pH 7, 15% recovery
작동 압력 ~1.0–1.6 MPa (150–225 psi) BW/LE; max 4.1 MPa (600 psi) per model limit
Feed Water Temperature 5–45 °C (flux rises with temperature)
pH Range (continuous / cleaning) 2–11 / 1–13
Free Chlorine Tolerance 0 mg/L (TFC polyamide is chlorine-sensitive; dechlorinate upstream)
Max Feed SDI < 5 recommended; lower for sensitive duties
Max Pressure Drop (per element) ≤ 1.0 bar (15 psi)
Recommended Recovery 10–20% per pressure vessel (system design-dependent)
End Connection Standard 4040 brine seal and interconnector; EPDM O-rings
Available Variants BW4040 (high rejection), LE4040 (low energy), FR4040 (fouling-resistant), SW4040 (seawater / higher pressure)
Test Conditions Note Unless stated otherwise: 2,000 ppm NaCl, 25 °C, pH 7, 15% recovery; your results vary with temperature and pressure.

해당 산업

  • Commercial & light-industrial RO systems for municipal/brackish feeds
  • Beverage & bottled water polishing
  • Boiler make-up & process water
  • Electronics pre-DI / polishing trains
  • Wastewater reuse after clarification/UF
  • Carwash, HVAC, humidification and rinsing lines

장점 1

Advantage 1 — High Rejection with Flexible Energy Window

  • Nominal ≥ 99% salt rejection on NaCl with stable permeate conductivity.
  • Low-energy (LE) options to reduce pump pressure and operating cost.
  • Fouling-resistant (FR) construction available for difficult feeds.

이점 2

Advantage 2 — Easy Retrofit & OEM Support

  • Compatible with standard 4040 pressure vessels and adapters.
  • OEM/Private label available; documentation and QC traceability provided.
  • Application engineering: element selection, pretreatment and dosing guidance based on your water analysis.

관련 제품

연관 상품

자주 묻는 질문

역삼투압 시스템의 수명은 수질과 유지 관리에 따라 달라집니다. 일반적으로 멤브레인의 수명은 2~3년이며, 시스템 자체는 적절한 관리를 통해 10년 이상 지속될 수 있습니다.

예, 모든 시스템은 완벽하게 사용자 정의할 수 있습니다. 고객의 수질 보고서와 애플리케이션 요구 사항을 분석하여 맞춤형 솔루션을 제공합니다.

당사의 제품은 CE, ISO 9001을 준수하며 요청에 따라 특정 지역 규정 또는 산업 표준을 충족하도록 설계할 수 있습니다.

표준 시스템은 7~15일 이내에 배송됩니다. 맞춤형 주문의 경우 복잡성에 따라 리드 타임이 20~25일로 연장될 수 있습니다.

예. 전체 기술 문서와 비디오를 통한 원격 지원을 제공하며, 요청 시 엔지니어를 해외로 파견할 수 있습니다.

견적에는 전체 RO 시스템, 제어판, 펌프, 전처리 장치 및 필요한 모든 피팅이 포함됩니다. 요청 시 설치 도구와 예비 부품도 포함될 수 있습니다.
