Stainless Steel RO Membrane Housing – 8″ Side Entry Series (300 PSI)
Industrial-grade 8-inch Stainless Steel RO Membrane Housing featuring a side-entry design for streamlined piping configurations. Constructed from heavy-duty SUS304 or 316L with seamless body options, this series is rated for 300 PSI and dramatically simplifies manifold connections for large-scale water treatment skids.
제품 설명
Streamlined Piping for Large-Scale Systems.
The Stark 8-inch Side Entry Membrane Housing is engineered for industrial RO plants where piping efficiency is paramount. Unlike end-entry models, our side-entry design allows feed and concentrate piping to connect directly to the side ports. This eliminates the need to disconnect plumbing during membrane change-outs and allows for compact, multi-vessel manifold configurations.
For applications demanding maximum durability and hygiene, we offer Seamless Body Models. These housings are manufactured from a single piece of stainless steel tubing without longitudinal welds, eliminating potential corrosion points and providing a mirror-smooth interior surface to prevent biofilm accumulation.
Technical Drawings & Seal Data:
The integrity of side-port sealing is critical for high-pressure operation. For detailed CAD drawings of the side-port structure, seamless tube wall thickness reports, and seal kit specifications, please reference the technical data at our manufacturing division:
Stark Manufacturing – 8″ Side Entry Housing Specs
.
제품 매개변수
Below are the specifications for our 8-inch Side Entry series. Standard models feature 1.5″ Feed/Concentrate ports for high-flow industrial applications.
| 모델 | Diameter | Housing Length | Side Inlet (Feed) | Side Outlet (Conc) | Action |
|---|---|---|---|---|---|
| STK-8040-1 | 8.0″ | 40″ (1 Element) | 1.5″ | 1″ | Inquiry |
| STK-8040-2 | 8.0″ | 80″ (2 Elements) | 1.5″ | 1″ | Inquiry |
| STK-8040-3 | 8.0″ | 120″ (3 Elements) | 1.5″ | 1″ | Inquiry |
| STK-8040-4 | 8.0″ | 160″ (4 Elements) | 1.5″ | 1″ | Inquiry |
| STK-8040-5 | 8.0″ | 200″ (5 Elements) | 1.5″ | 1″ | Inquiry |
| STK-8040-6 | 8.0″ | 240″ (6 Elements) | 1.5″ | 1″ | Inquiry |
| STK-8040-1-SM (Seamless) | 8.0″ | 40″ (1 Element) | 1.5″ | 1″ | Inquiry |
*Inlet Connection: 1.5″ (DN40). Outlet Connection: 1″. Seamless models feature single-piece tube construction for enhanced durability.
해당 산업
- Industrial Wastewater Recycling:
Robust stainless steel construction withstands harsh chemical cleaning and aggressive wastewater conditions. - Large Scale Beverage Production:
Seamless sanitary models ensure zero bacterial growth for high-volume bottling plants. - Brackish Water Desalination:
Standard 8-inch housing for BWRO applications requiring reliable 300 PSI operation.
장점 1
Side Entry Design Efficiency
The “Side Entry” configuration is a game-changer for large multi-vessel systems. By locating the feed and concentrate ports on the side of the vessel, installers can manifold multiple housings together with shorter pipe runs and fewer fittings. This design also simplifies maintenance, as the end caps can be removed for membrane replacement without disconnecting the main plumbing lines, saving hours of labor.이점 2
Seamless Body Durability
For critical applications, Stark offers Seamless Stainless Steel Housings. These units are crafted from a continuous steel tube, eliminating the longitudinal weld seam found in standard models. This seamless construction provides higher structural integrity under pressure and a perfectly smooth interior surface, significantly reducing the risk of crevice corrosion and bacterial adhesion.관련 제품
연관 상품
자주 묻는 질문
Q1: 역삼투압 시스템의 수명은 얼마나 되나요?
역삼투압 시스템의 수명은 수질과 유지 관리에 따라 달라집니다. 일반적으로 멤브레인의 수명은 2~3년이며, 시스템 자체는 적절한 관리를 통해 10년 이상 지속될 수 있습니다.
Q2: 다양한 수질 조건에 따라 시스템을 맞춤 설정할 수 있나요?
예, 모든 시스템은 완벽하게 사용자 정의할 수 있습니다. 고객의 수질 보고서와 애플리케이션 요구 사항을 분석하여 맞춤형 솔루션을 제공합니다.
Q3: STARK 장비는 어떤 표준을 준수하나요?
당사의 제품은 CE, ISO 9001을 준수하며 요청에 따라 특정 지역 규정 또는 산업 표준을 충족하도록 설계할 수 있습니다.
Q4: STARK RO 시스템의 배송 시간은 어떻게 되나요?
표준 시스템은 7~15일 이내에 배송됩니다. 맞춤형 주문의 경우 복잡성에 따라 리드 타임이 20~25일로 연장될 수 있습니다.
Q5: 기술 지원이나 설치 안내를 제공하나요?
예. 전체 기술 문서와 비디오를 통한 원격 지원을 제공하며, 요청 시 엔지니어를 해외로 파견할 수 있습니다.
Q6: 견적에는 무엇이 포함되나요?
견적에는 전체 RO 시스템, 제어판, 펌프, 전처리 장치 및 필요한 모든 피팅이 포함됩니다. 요청 시 설치 도구와 예비 부품도 포함될 수 있습니다.
