Корпус мембраны системы обратного осмоса FRP 4040 UF Корпус мембраны для мембраны обратного осмоса
Secure robust and corrosion-resistant containment for your membranes with Stark Water’s RO System FRP Membrane Housing 4040. This durable FRP membrane housing is designed for standard 4040 RO and UF elements, providing reliable, leak-proof performance crucial for various industrial and commercial water treatment systems.
Product Description
The efficiency and longevity of Reverse Osmosis (RO) and Ultrafiltration (UF) systems hinge significantly on the integrity and material quality of their membrane housings. The Stark Water RO System FRP Membrane Housing 4040 offers a superior solution, engineered specifically for outstanding corrosion resistance, durability, and reliable performance. This FRP membrane housing is a cornerstone component for a wide array of water purification plants, ensuring the secure containment of valuable membrane elements.
The Unmatched Benefits of FRP Membrane Housing
Our FRP membrane housing is constructed from Fiber Reinforced Plastic (FRP), a material renowned for its exceptional properties in challenging water treatment environments:
- Superior Corrosion Resistance: Unlike some metallic housings, FRP is inherently resistant to a broad spectrum of chemicals, acids, and bases often found in feedwater or used during membrane cleaning. This makes it ideal for applications involving corrosive water sources or specific industrial processes, ensuring a longer lifespan and preventing material degradation.
- High Strength-to-Weight Ratio: FRP offers excellent mechanical strength while being significantly lighter than stainless steel or carbon steel alternatives. This facilitates easier installation, reduces shipping costs, and puts less structural strain on your system framework.
- Cost-Effectiveness: FRP membrane housings often present a more economical solution compared to high-grade stainless steel options, particularly for applications where corrosive resistance is critical but budget is a concern.
- Smooth Internal Surface: The interior surface of FRP housings is typically smooth, minimizing potential for bacterial growth and simplifying cleaning processes.
This inherent robustness and material advantage ensure reliable, long-term performance, even under continuous industrial operation.
Precision Fit for 4040 RO and UF Membranes
This specific housing is meticulously designed to perfectly accommodate standard 4040 RO membrane elements (4-inch diameter, 40-inch length) and can also serve as a UF membrane housing for RO membrane pre-treatment or standalone UF applications, where 4040 sized UF modules are used. The precise internal dimensions ensure an optimal fit for the membrane, preventing bypass of untreated water and maximizing the efficiency of the filtration or reverse osmosis process. This universal compatibility with 4040 elements, whether for UF or RO, makes it a versatile choice for system builders and operators seeking reliable and flexible membrane containment.
Reliable Performance and System Protection
The Stark Water 4040 FRP Membrane Housing is designed for consistent, leak-proof performance under rated operating pressures. Its robust construction ensures the safe containment of membranes, protecting them from external damage and contributing to the overall integrity of your RO system or UF system. By providing a secure and stable environment for the membranes, it helps achieve optimal permeate flow and contaminant rejection, thereby extending the lifespan of the membranes and safeguarding the purity of your treated water.
Product Parameter
| Parameter | Specification / Customization Options |
|---|---|
| Core Keyword Focus | FRP membrane housing design and capabilities. |
| Compatible Membrane Size | 4040 (4-inch diameter x 40-inch length) RO Membrane Elements and UF Membrane Elements. Available for 1 to 3+ elements per vessel. |
| Material Construction | Fiber Reinforced Plastic (FRP) with a high-quality liner (e.g., Polyethylene, Polypropylene, or Epoxy Vinyl Ester). |
| Max. Operating Pressure | Typically 300 PSI, 450 PSI, 600 PSI, or 1000 PSI for high-pressure RO applications. |
| Design Type | End-entry or Side-entry ports. Multi-port options available. |
| Port Connections | Threaded (NPT/BSP) or Flanged connections. |
| End Cap Material | Durable ABS, PVC, or fiberglass-reinforced composite material. |
| Sealing Material | EPDM, Viton (FKM), or Buna-N (NBR) O-rings, selected based on temperature and chemical compatibility. |
| External Finish | Standard gel coat (various colors available) or painted. |
| Max. Operating Temperature | Up to 49°C (120°F) for standard seals and materials; higher with specialized materials. |
| Mounting Hardware | Includes stainless steel mounting saddles and straps. |
| Testing & Certification | Hydrostatic pressure tested; designed to relevant industry standards. |
| Corrosion Resistance | Excellent resistance to chemicals, acids, bases, and aggressive feedwaters. |
Applicable Industry
- Brackish Water Reverse Osmosis Systems: Essential for containing RO membranes in systems purifying brackish groundwater for municipal drinking water, industrial process water, or agricultural irrigation, where FRP’s corrosion resistance is beneficial.
- Commercial & Industrial RO Systems (General): For containing 4040 RO membranes in medium-scale RO plants providing pure water for various manufacturing processes, utility, and general industrial use.
- Ultrafiltration (UF) Systems: Acts as a robust UF membrane housing for 4040 UF elements, used for pre-treatment to RO, drinking water purification, or industrial water clarification, benefiting from FRP’s durability.
- Food & Beverage Industry: For RO or UF systems producing high-purity water for beverage formulation, dairy processing, and food ingredient preparation, where hygienic and corrosion-resistant components are valued.
- Pharmaceutical (Utility Water): Used in RO or UF systems generating purified water for non-critical utility applications, benefiting from material integrity in sensitive environments.
- Water Treatment Plants (Various): Integrated into diverse water treatment plants requiring robust containment for membrane filtration stages.
- Laboratories & Research Facilities: For RO or UF systems supplying purified water for various lab operations.
- Wastewater Treatment & Reuse: Applied in advanced filtration stages for industrial or municipal wastewater, where FRP’s chemical resistance is advantageous for treating challenging effluents.
- Agricultural Applications: For RO or UF systems treating irrigation water where the raw water might be slightly corrosive or require a lightweight, durable housing solution.
Advantage One
Advantage TWO
Related Products
Похожие товары
FAQ
Q1: How long does the reverse osmosis system last?
The lifespan of a reverse osmosis system depends on water quality and maintenance. Typically, the membrane lasts 2–3 years, while the system itself can last over 10 years with proper care.
Q2: Can the system be customized based on different water conditions?
Yes, all our systems are fully customizable. We analyze your water report and application needs before providing tailored solutions.
Q3: What standards does STARK equipment comply with?
Our products comply with CE, ISO 9001, and can be designed to meet specific regional regulations or industry standards upon request.
Q4: What is the delivery time for STARK RO systems?
Standard systems are shipped within 7–15 days. For customized orders, lead time may extend to 20–25 days depending on complexity.
Q5: Do you provide technical support or installation guidance?
Yes. We provide full technical documentation, remote guidance via video, and can dispatch engineers internationally upon request.
Q6: What is included in your quotation?
Our quotation includes the full RO system, control panel, pumps, pre-treatment units, and all necessary fittings. Installation tools and spare parts can be included upon request.
