water reverse osmosis system
Discover the best water reverse osmosis system with Stark Water’s STK-4T ODM Reverse Osmosis Drinking Water System. Designed for robust performance, this high-capacity water reverse osmosis system is ideal for large-scale sea water purification and industrial chemical water treatment plant applications, delivering superior purity and efficiency.
Product Beschrijving
In today’s global landscape, access to reliable sources of pure water is more critical than ever, especially for large-scale industrial operations and potable water supply from challenging sources like seawater. The STARK STK-4T ODM Best Water Reverse Osmosis System is engineered to meet these immense demands, offering an unparalleled solution for high-capacity purification, whether for drinking water or complex industrial processes. This is more than just a system; it’s a comprehensive **water reverse osmosis system** designed for ultimate performance and adaptability.
The Pinnacle of Water Reverse Osmosis System Technology
Our STK-4T system embodies the highest standards of **reverse osmosis** technology. It employs advanced thin-film composite (TFC) membranes and precision-engineered components to achieve exceptional contaminant rejection rates. This system effectively removes up to 99.5% of dissolved salts, minerals, heavy metals, organic compounds, bacteria, viruses, and other impurities from various raw water sources. The “4T” in its name signifies a substantial capacity, typically referring to 4 tons per hour or 4 m³ per hour (4,000 liters per hour), making it ideal for large-scale production requirements. This high-capacity output ensures a continuous and reliable supply of purified water for even the most demanding applications.
Versatility: From Sea Water Purification to Drinking Water Systems
A key strength of the STARK STK-4T system is its remarkable versatility, particularly its capability for **sea water purification**. While often used for brackish or municipal water sources, this system can be specifically optimized for desalination, transforming highly saline seawater into fresh, potable water. This makes it an invaluable asset for coastal communities, offshore platforms, and island nations grappling with freshwater scarcity. Moreover, as an **ODM (Original Design Manufacturer)** product, it offers unparalleled customization. This means the system can be precisely tailored to meet the specific requirements of various feed water qualities, desired product water standards, and unique site conditions, ensuring it functions as the **best water reverse osmosis system** for your exact needs.
When configured as a **drinking water system**, it ensures that treated water meets or exceeds international potable water standards, providing safe and pleasant-tasting water for large populations. Its robust purification stages can effectively handle a wide range of raw water challenges, ensuring consistent output quality.
Integral to Chemical Water Treatment Plant Operations
The STARK STK-4T RO system is also designed for seamless integration as a core component within a broader **chemical water treatment plant**. It can serve as the primary purification stage, producing high-quality permeate that can then be further polished by technologies like EDI (Electrodeionization) or mixed-bed ion exchange for ultra-pure applications. Its high efficiency in removing a vast array of contaminants reduces the chemical burden on subsequent treatment stages, contributing to a more economical and environmentally responsible overall plant operation. This makes it an indispensable asset for industries that require both high volume and precise water quality for their manufacturing processes, chemical formulations, or boiler feed applications.
Reliability, Efficiency, and Long-Term Value
Built with durability in mind, the STARK STK-4T **water reverse osmosis system** features robust construction and high-quality components, ensuring a long operational lifespan and minimal downtime. Its automated controls provide real-time monitoring and operational safeguards, simplifying management and ensuring consistent performance. The inherent efficiency of RO technology, coupled with our optimized system design, translates into lower energy consumption and reduced chemical usage compared to traditional methods, offering significant long-term cost savings and an excellent return on investment.
Product Parameter
Parameter | Specificatie/aanpassingsopties |
---|---|
Kern trefwoord focus | Water reverse osmosis system design and performance. |
Pure Water Capacity | 4 m³ per Hour (4,000 Liters Per Hour / approx. 17.6 GPM) – Representing “STK-4T”. Custom capacities available. |
Raw Water Source Compatibility | Municipal Tap Water, Well Water, Brackish Water (TDS up to 10,000 ppm for standard BWRO), or Seawater (TDS up to 45,000 ppm for SWRO configuration). |
RO Membrane Type | High-rejection Thin-Film Composite (TFC) RO Membranes (e.g., 8040 series, quantity sized for capacity/TDS). Specifically SWRO membranes for seawater. |
High-Pressure Pump | Energy-efficient, corrosion-resistant centrifugal or positive displacement pump (e.g., Grundfos, Danfoss, CNP), sized for specific flow and pressure. |
Pre-treatment System |
|
Salt Rejection Rate | ≥98% – 99.5% (for BWRO); ≥99.5% – 99.7% (for SWRO) |
Water Recovery Rate | 50% – 75% (BWRO); 30% – 50% (SWRO) – Dependent on raw water quality and system design. |
Output Water Quality | TDS <100 ppm (for drinking water/process); significantly lower for high-purity applications after post-treatment. Meets WHO standards for drinking water. |
Voeding | 3 Phase, 380V/415V/460V, 50Hz/60Hz (Customizable as per regional standards). |
Besturingssysteem | Fully Automatic PLC Control with real-time online conductivity/TDS meter, pressure gauges, flow meters, auto-flush, low/high pressure protection, and fault alarms. |
Construction Material |
|
Inlet Water Requirements |
|
Dimensions (Approximate) | Varies significantly based on customization and capacity (e.g., L 3000mm x W 1200mm x H 2000mm for 4m³/hr). |
Bedrijfstemperatuur | 5°C – 45°C. |
Customization | ODM (Original Design Manufacturer) capabilities for tailored solutions. |
Toepasselijke industrie
- Municipal Drinking Water Supply: Provides large volumes of safe, potable drinking water for towns, cities, or communities, especially in areas with limited freshwater resources or high raw water TDS.
- Coastal Communities & Island Nations: Essential for **sea water purification**, transforming abundant saline water into a reliable source of fresh drinking and utility water, addressing water scarcity.
- Hotels, Resorts & Large Residential Complexes: Ensures a continuous supply of high-quality drinking water and utility water for guests and residents, enhancing comfort and facility operations.
- Food & Beverage Industry: Used as the primary purification stage for process water in beverage production (bottled water, soft drinks, juices, beer), dairy processing, and food ingredient preparation, ensuring product purity, consistency, and safety.
- Pharmaceutical & Medical Industry (Pre-Treatment): Provides highly purified water for pre-treatment stages to produce Purified Water (PW) or Water for Injection (WFI), crucial for drug manufacturing, laboratories, and medical device reprocessing.
- Electronics & Semiconductor Manufacturing (Pre-Treatment): Produces high-purity water for pre-treatment to generate ultra-pure water (UPW) used in chip fabrication and component rinsing, preventing contamination.
- Power Generation: Utilized for boiler feed water pre-treatment, cooling tower make-up water, and turbine washing in power plants, preventing scaling and corrosion and improving energy efficiency.
- Chemical Industry (Chemical Water Treatment Plant): Serves as a core component in **chemical water treatment plants**, supplying large volumes of purified water for chemical formulations, dilutions, and various process applications, ensuring product purity and preventing unwanted reactions.
- Agricultural Irrigation (Specific Applications): For large-scale treatment of brackish water for specialized crop irrigation or hydroponics, where specific water quality is critical for plant health and yield.
- Wastewater Treatment & Reuse: Employed in advanced wastewater treatment facilities to produce high-quality effluent suitable for discharge, industrial reuse, or even aquifer recharge.
Voordeel één
Voordeel TWEE
Verwante producten
Gerelateerde producten
FAQ
V1: Hoe lang gaat het omgekeerde osmose systeem mee?
De levensduur van een omgekeerd osmose systeem hangt af van de waterkwaliteit en het onderhoud. Het membraan gaat meestal 2-3 jaar mee, terwijl het systeem zelf meer dan 10 jaar kan meegaan als het goed onderhouden wordt.
V2: Kan het systeem worden aangepast aan verschillende wateromstandigheden?
Ja, al onze systemen zijn volledig aanpasbaar. We analyseren uw waterrapport en toepassingsbehoeften voordat we oplossingen op maat bieden.
V3: Aan welke normen voldoet de apparatuur van STARK?
Onze producten voldoen aan CE, ISO 9001 en kunnen op verzoek worden ontworpen om te voldoen aan specifieke regionale voorschriften of industrienormen.
V4: Wat is de levertijd voor STARK RO-systemen?
Standaardsystemen worden binnen 7-15 dagen verzonden. Voor aangepaste bestellingen kan de levertijd oplopen tot 20-25 dagen, afhankelijk van de complexiteit.
V5: Biedt u technische ondersteuning of begeleiding bij de installatie?
Ja. We bieden volledige technische documentatie, begeleiding op afstand via video en kunnen op verzoek technici internationaal sturen.
V6: Wat is inbegrepen in jullie offerte?
Onze offerte omvat het volledige RO-systeem, het bedieningspaneel, de pompen, de voorbehandelingsunits en alle benodigde appendages. Installatiegereedschap en reserveonderdelen kunnen op verzoek worden meegeleverd.
