Industrial High-Flow EDI Module for Ultra Pure Water Systems | COVNA STARK
The IONTECH IT-VNS MAX Industrial High-Flow EDI Module is a high-capacity continuous electrodeionization (EDI) solution designed for industrial ultrapure water systems. Delivering product water resistivity above 17–18 MΩ·cm, over 95% silica and boron removaloraz 99.8% sodium and chloride removal, it provides continuous chemical-free operation for power plants, semiconductor manufacturing, pharmaceutical production, and other demanding high-purity water applications.
Opis produktu
High-Flow Industrial EDI Module for Continuous Ultrapure Water Production
The IT-VNS MAX Industrial High-Flow EDI Module is engineered to deliver reliable, high-purity water for industrial applications requiring continuous operation and exceptional water quality. Utilizing advanced continuous electrodeionization (CEDI) technology, the module removes dissolved ions from RO permeate or DI water without chemical regeneration, ensuring stable performance while reducing operating costs and environmental impact.
Designed for industries with strict water quality requirements, the IT-VNS MAX produces ultrapure water with product resistivity exceeding 17 MΩ·cm when fed with RO permeate and 18 MΩ·cm when supplied with DI water. The module also achieves over 95% removal of silica and boron, while reducing sodium and chloride by 99.8%, making it suitable for ultra-supercritical boiler feedwater, semiconductor manufacturing, pharmaceutical production, and precision electronics.
The module features an integrated junction box with excellent electrical insulation, a double O-ring sealing structure for leak-free operation, and supports both horizontal and vertical installation. Operating continuously at pressures up to 7 bar (100 psi) and temperatures up to 45°C, it provides long-term reliability for industrial ultrapure water systems.
With no need for acid/alkali regeneration or mixed-bed resin replacement, the IT-VNS MAX significantly simplifies system operation while lowering maintenance costs.
Parametr produktu
| Parametr | Specyfikacja |
|---|---|
| Źródło wody zasilającej | RO Permeate or DI Water |
| Conductivity (Including CO₂ & Silica) | ≤40 μS/cm |
| Silica (SiO₂) | <1.0 ppm |
| Iron (Fe, Mn, S) | <0.01 ppm |
| Total Chlorine (Cl₂) | <0.02 ppm |
| Total Hardness (CaCO₃) | <1.0 ppm |
| TOC | <0.5 ppm |
| pH | 4–11 |
| Feed Water Temperature | 5–45°C |
| Maximum Inlet Pressure | 7 bar (100 psi) |
Obowiązująca branża
The IT-VNS MAX Industrial EDI Module is widely used in:
- Ultra-Supercritical Boiler Feedwater Systems
- Power Plants
- Produkcja półprzewodników
- Microelectronics Industry
- Pharmaceutical Production
- Biotechnology Facilities
- High-Purity Chemical Manufacturing
- Precision Electronics
- Laboratory Ultrapure Water Systems
- Food & Beverage High-Purity Water
- Industrial Ultrapure Water Plants
- Reverse Osmosis + EDI Systems
Advantage One
Continuous Chemical-Free Operation
Eliminates the need for acid and alkali regeneration, reducing operating costs and environmental impact.
Excellent Water Quality
Produces ultrapure water with resistivity above 17–18 MΩ·cm, meeting demanding industrial requirements.
High Ion Removal Efficiency
- Silica >95%
- Boron >95%
- Sodium 99.8%
- Chloride 99.8%
Stable Long-Term Performance
Continuous operation ensures consistent water quality without the fluctuations associated with mixed-bed resin regeneration.
Double O-Ring Leak Protection
Advanced sealing technology provides reliable, leak-free operation under industrial conditions.
Flexible Installation
Supports both horizontal and vertical installation, making system integration easier.
High Electrical Safety
Integrated junction box with excellent insulation ensures safe and reliable electrical connections.
Lower Operating Costs
No resin replacement or chemical regeneration systems are required, reducing maintenance and simplifying plant operation.
Przewaga DWÓCH
✔ Product water resistivity >17 MΩ·cm
✔ Designed for ultra-supercritical boiler feedwater
✔ Silica removal rate >95%
✔ Boron removal rate >95%
✔ Continuous operation without chemical regeneration
✔ Stable water quality with no conductivity fluctuations
✔ No mixed-bed resin replacement required
✔ No acid or alkali regeneration chemicals
✔ Integrated junction box with excellent electrical insulation
✔ Double O-ring sealing structure for leak-free operation
✔ Supports horizontal or vertical installation
✔ Continuous operation at 7 bar (100 psi) oraz 45°C (113°F)
