The IT-DS Series Industrial EDI Module is a continuous electrodeionization (EDI) solution designed for industrial ultrapure water production. Delivering product water resistivity up to 17 MΩ·cm at nominal flow, silica removal up to 99%, and continuous chemical-free operation, it is ideal for pharmaceutical, electronics, power generation, food processing, laboratories, and industrial RO-EDI water treatment systems.
Opis produktu
Reliable Continuous Electrodeionization for Industrial High-Purity Water
The IT-DS Series Industrial EDI Module is designed to provide stable, continuous production of high-purity water without the need for chemical regeneration. By combining ion exchange membranes with an electrically regenerated resin bed, the module continuously removes dissolved ions from RO permeate, eliminating the downtime and maintenance associated with conventional mixed-bed resin systems.
Compared with traditional ion exchange technology, the IT-DS Series offers better water quality, lower operating costs, and environmentally friendly performance by eliminating acid and alkali regeneration chemicals.
Manufactured with durable engineering materials and equipped with double O-ring sealing technology, the module ensures reliable leak-free operation and excellent electrical insulation. The IT-DS Series supports continuous operation at pressures up to 7 bar (100 psi) and temperatures up to 45°C (113°F), making it suitable for a wide range of industrial ultrapure water applications.
Available in capacities from 0.44 to 5.0 m³/h, the IT-DS Series can be integrated into both new and existing RO + EDI water treatment systems.
Parametr produktu
| Parametr | Specyfikacja |
|---|---|
| Źródło wody zasilającej | 2RO Permeate |
| Feed Water Conductivity | ≤10 μS/cm |
| Silica (SiO₂) | <1 ppm |
| Iron (Fe, Mn, S) | <0.01 ppm |
| Chlor całkowity | <0.02 ppm |
| Total Hardness (CaCO₃) | <1.0 ppm |
| TOC | <0.5 ppm |
| pH | 4–11 |
| Feed Water Temperature | 5–45°C |
| Maximum Inlet Pressure | <7 bar (100 psi) |
Obowiązująca branża
The IT-DS Series is suitable for:
- Industrial Ultrapure Water Systems
- Pharmaceutical Water Systems
- Produkcja półprzewodników
- Electronics Industry
- Power Plants
- Boiler Feed Water Systems
- Przetwarzanie chemiczne
- Food & Beverage Production
- Laboratory Water Systems
- Biotechnology Facilities
- Precision Manufacturing
- RO + EDI Water Purification Systems
Advantage One
Continuous Chemical-Free Operation
No acid or alkali regeneration is required, reducing operating costs and environmental impact.
Stable High-Purity Water
Produces consistent high-quality water with resistivity up to 17 MΩ·cm under specified operating conditions.
High Silica Removal
Achieves 90–99% silica removal, depending on feed water quality.
Double O-Ring Leak Protection
Provides reliable sealing for long-term, leak-free operation.
Excellent Electrical Insulation
Designed with strong insulation performance for safe and reliable operation.
Wide Capacity Range
Five models available, covering 0.44 to 5.0 m³/h nominal flow to suit different industrial requirements.
Easy Integration
Supplied with metric and imperial conversion fittings and a 3-meter cable for convenient installation.
Przewaga DWÓCH
✔ No acid and alkali regeneration required
✔ Stable high water resistivity output
✔ Low operating and maintenance cost
✔ Environmentally friendly operation
✔ Compact modular structure
✔ Easy integration with RO systems
✔ Long service life
Powiązane produkty
Podobne produkty
FAQ
P1: Jak długo działa system odwróconej osmozy?
Żywotność systemu odwróconej osmozy zależy od jakości wody i konserwacji. Zazwyczaj membrana wytrzymuje 2-3 lata, podczas gdy sam system może wytrzymać ponad 10 lat przy odpowiedniej pielęgnacji.
P2: Czy system można dostosować do różnych warunków wodnych?
Tak, wszystkie nasze systemy są w pełni konfigurowalne. Analizujemy raporty wodne i potrzeby aplikacji przed dostarczeniem dostosowanych rozwiązań.
P3: Jakie standardy spełnia sprzęt STARK?
Nasze produkty są zgodne z normami CE, ISO 9001, a na życzenie mogą być zaprojektowane tak, aby spełniały określone przepisy regionalne lub normy branżowe.
P4: Jaki jest czas dostawy systemów STARK RO?
Standardowe systemy są wysyłane w ciągu 7-15 dni. W przypadku niestandardowych zamówień czas realizacji może wydłużyć się do 20-25 dni w zależności od złożoności.
P5: Czy zapewniasz wsparcie techniczne lub wskazówki dotyczące instalacji?
Tak. Zapewniamy pełną dokumentację techniczną, zdalne wskazówki za pośrednictwem wideo, a na życzenie możemy wysłać inżynierów za granicę.
P6: Co jest zawarte w wycenie?
Nasza oferta obejmuje kompletny system RO, panel sterowania, pompy, jednostki oczyszczania wstępnego i wszystkie niezbędne elementy. Narzędzia instalacyjne i części zamienne mogą być dołączone na życzenie.
